| Brand | Premium-NDAA |
|---|
| Model | HNC6D42NIU |
|---|
| Image Sensor | Dual 4MP 1/2.7-in. CMOS sensor |
|---|
| Maximum Resolution | 2688 x 1520 |
|---|
| Minimum Illumination | Color: 0.0007 Lux at F1.6 0 Lux with IR on |
|---|
| Number of Illuminators | 8 IR LEDs, 4 per Sensor |
|---|
| Illuminator Control | Automatic, Manual |
|---|
| Maximum Illumination Distance | Up to 30 m (100 ft) |
|---|
| Electronic Shutter Speed | Automatic, Manual 1/3 s to 1/100,000 s |
|---|
| Installation Angle | Pan: 0° to 360° Tilt: 0° to 78° Rotation: 0° to 360° |
|---|
| S/N Ratio | > 56 dB |
|---|
| Iris Type | Fixed |
|---|
| Lens Type | Fixed |
|---|
| Focal Length | 2.8 mm |
|---|
| Maximum Aperture | F1.6 |
|---|
| Field of View | Horizontal: 101° Vertical: 54 ° Diagonal: 120° |
|---|
| Close Focus Range | 1.1 m (3.6 ft) |
|---|
| DORI Distance | Detect : 63.1 m (207.0 ft) Observe : 25.0 m (82.0 ft) Recognize : 12.5 m (41.0 ft) Identify : 6.3 m (20.7 ft) |
|---|
| Compression | H.264, H. 265, Smart Encoding H.265, Smart Encoding H.264, MJPEG (Sub Stream 1 Only) |
|---|
| Standard Codec | Supported |
|---|
| Stream Capability | Two (2) |
|---|
| Resolution | 4MP (2688 x 1520), 4MP (2560 x 1440), 3MP (2048 x 1536/2304 x 1296), 1080p (1920 x 1080), 1.3MP (1280 x 960), 720P (1280 x 720), D1 (704 x 480), VGA (640 x 480), CIF (352 x 240) |
|---|
| Maximum Frame Rate | Main Stream : 2688 x 1520 at 20 fps Sub Stream 1 : D1 at 30 fps Sub Stream 2 : 1080p at 30 fps |
|---|
| Video Bit Rate | H.264: 3 kbps to 10,240 kbps H.265: 3 kbps to 10,240 kbps |
|---|
| Bit Rate Control | CBR/VBR |
|---|
| Day/Night | Color, Black and White |
|---|
| Noise Reduction | 3D NR |
|---|
| Light Balancing | Wide Dynamic Range (120 dB) |
|---|
| Image Angle | 0°/90°/180°/270° |
|---|
| Mirror Rotation | Supported |
|---|
| Region of Interest | Four (4) Zones |
|---|
| Privacy Masking | Four (4) Zones |
|---|
| Video Content Analytics | Line Crossing, Intrusion |
|---|
| Smart Motion Detection | Supported with Alarms for Vehicles and Humans |
|---|
| Compression | G.711a, G.711Mu, PCM |
|---|
| Interface | Input: Built-In Microphone and 1 channel output: 1 channel |
|---|
| Event | Line Crossing, Intrusion, Motion Detection, Smart Motion, Audio Detection, Video Tampering, Disk Full, Disk Error, Offline, IP Conflict, Voltage Detection, Security Warning |
|---|
| Interface | RJ-45 (10/100 Base-T) |
|---|
| Protocol | Pv4, IPv6, DNS, TCP, UDP, DHCP, HTTP, HTTPS, 802.1X, RTSP, DDNS, P2P, SMTP, RTMP, UPnP, Auto Registration, ICMP, IGMP, FTP, SFTP, RTP, RTCP, ARP, NTP, Multicast, NFS |
|---|
| Interoperability | ONVIF (Profile S/G/T), CGI |
|---|
| Browser | Chrome, Firefox, Edge |
|---|
| Storage | FTP, SFTP, MicroSD Card (Max. 256 GB), NAS |
|---|
| Power Supply | 12 VDC, PoE (802.3af) |
|---|
| Power Consumption | Maximum : 13.0 W Standard : 4.8 W |
|---|
| Net Weight | 0.6 kg (1.4 lb) |
|---|
| Gross Weight | 0.8 kg (1.8 lb) |
|---|
| Operating Temperature | -40 to 60 °C (-40 to 140 °F) < 95% RH (Non-Condensing) |
|---|
| Storage Temperature | -40 to 60 °C (-40 to 140 °F) |
|---|
| Protection Ratings | IP67, IK10 |
|---|
| Product Dimensions (L x W x H) | 164.0 mm x 84.0 mm x 69.4 mm (6.46 in. x 3.31 in. x 6.7 in.) |
|---|
| Packaging demention | 205.0 mm x 121.0 mm x 101.0 mm (8.1 in. x 4.8 in. x 4.0 in.) |
|---|
| Material | Metal |
|---|
| Certifications | FCC, IC |
|---|
| Compliance | NDAA |
|---|
| Electrical Box | HTH-280ZJ-DE7 |
|---|
| Wall Mount | HTH-272ZJ-DE7 |
|---|
| Pendant | HTH-271ZJ-DE7 |
|---|
| 2 to 4 ft. Telescope Mount | HTH-271NJ-DE7-24 |
|---|
| 3 to 6 ft. Telescope Mount | HTH-271NJ-DE7-36 |
|---|
