Lysora L6Pro-T AX3000 Wi-Fi 6 Outdoor Access Point
Lysora L6Pro-T AX3000 Wi-Fi 6 Outdoor Access Point - Image 2
Lysora L6Pro-T AX3000 Wi-Fi 6 Outdoor Access Point - Image 3
Lysora L6Pro-T AX3000 Wi-Fi 6 Outdoor Access Point - Image 4

L6Pro-T

Lysora AX3000 Wi-Fi 6 Outdoor Access Point

Port Configuration
1 × Gigabit RJ45; 1 × 1G SFP
Wi-Fi Bands
2.4 GHz; 5 GHz
Power Input
802.3at PoE+; 802.3af supported with reduced 5 GHz performance

$338.00

The Lysora L6Pro-T delivers AX3000-class Wi-Fi 6 in an IP68 outdoor enclosure. Dual-band 2×2 MU-MIMO radios connect through Gigabit RJ45 or Gigabit SFP interfaces, giving installers copper and fiber options for an outdoor wireless network.

  • AX3000-class dual-band Wi-Fi 6
  • 573 Mbps at 2.4 GHz and 2401 Mbps at 5 GHz
  • One Gigabit RJ45 port plus one Gigabit SFP port
Check CompatibilitySend your equipment model and setup details, and we’ll help check compatibility.

Accessories & compatibility

Product Information
SKU: L6Pro-T Category: Tags: , , , , , , , Brand:

Description

Lysora L6Pro-T AX3000 Wi-Fi 6 Outdoor Access Point

The Lysora L6Pro-T delivers AX3000-class Wi-Fi 6 in an IP68 outdoor enclosure. Dual-band 2×2 MU-MIMO radios connect through Gigabit RJ45 or Gigabit SFP interfaces, giving installers copper and fiber options for an outdoor wireless network.

Key Features

  • AX3000-class dual-band Wi-Fi 6
  • 573 Mbps at 2.4 GHz and 2401 Mbps at 5 GHz
  • One Gigabit RJ45 port plus one Gigabit SFP port
  • IP68 enclosure with −30°C to 65°C operating range
  • Wall and pole mounts included
  • Lysora Cloud, mesh, roaming and VLAN support

Designed For Your Network

For outdoor guest or staff coverage, wall and pole mounting make it easier to position the access point around a site. Its specified operating range extends from −30°C to 65°C.

For installations with fiber infrastructure, the Gigabit SFP port offers a useful connection option alongside the PoE-capable copper port. Choose the power and uplink arrangement to suit the site layout.

For multi-access-point deployments, cloud management, wireless meshing and roaming support help coordinate coverage. VLANs, client isolation and captive portal controls provide policies for different groups of users.

Installation And Power

  • Outdoor IP68 enclosure; wall and pole mounts are included.
  • Use 802.3at PoE+ for full performance. The datasheet says 802.3af operation reduces the 5 GHz wireless rate to 60% of its original rate.
  • Select a compatible power source and any required SFP module for the installation.

Management And Resources

Access supported devices through Lysora Cloud or the Lysora Cloud mobile app. Available functions depend on the model and firmware. Use the Downloads tab for verified app and document links.

View Official L6Pro-T Product Information

Additional information

Weight 10.5 lbs
Dimensions 9 × 7.7 in
Brand

Lysora
Model

L6Pro-T
Product Type

Outdoor Access Point
Port Configuration

1 × Gigabit RJ45; 1 × 1G SFP
Wi-Fi Standard

Wi-Fi 6 (802.11ax)
Wi-Fi Bands

2.4 GHz; 5 GHz
Power Input

802.3at PoE+; 802.3af supported with reduced 5 GHz performance
Mounting

Wall; Pole (Mounts Included)

PLAN YOUR INSTALLATION

Accessories

Help me choose

Need help choosing an accessory for this product? Ask us to confirm compatibility before ordering.

Ask about compatible accessories

Downloads & Support

L6Pro-T

Use the exact model, hardware revision and region when selecting firmware or documents. The official Download Center may require sign-in; no individual firmware file is supplied here.

Need Help With This Product?

Technical Specifications

BrandLysora
ModelL6Pro-T
DimensionsØ230 mm x 195 mm (Ø9.06 in. x 7.68 in.) (spherical device, excluding the mounting bracket)
Weight≤ 1.4 kg (3.09 lbs.) (without packaging materials)
Wi-Fi StandardsIEEE 802.11 a/b/g/n/ac/ax
Spatial Streams4
Manufacturer Coverage Estimate5 GHz max: 400 m (1312.34 ft.) 2.4 GHz max: 150 m (492.13 ft.) 5 GHz recommended: 200 m (656.17 ft.) 2.4 GHz recommended: 50 m (164.04 ft.) Note: The data is obtained in an ideal environment without obstruction. The signal coverage radius depends on client performance and environmental interference.
Ethernet Interfaces(1) 1GbE RJ45 port (1) 1GbE SFP port
Radio Bands And Protocols2.4 GHz:IEEE 802.11 b/g/n/ax 5 GHz:IEEE 802.11 a/n/ac/ax
MIMO2.4 GHz: 2 x 2 MU-MIMO 5 GHz: 2 x 2 MU-MIMO
Channel Bandwidth2.4 GHz: 20/40 MHz 5 GHz: 20/40/80/160 MHz
Wireless PHY Data Rates2.4 GHz: 573 Mbps 5 GHz: 2401 Mbps
Antenna Gain2.4 GHz: 3.00 dBi 5 GHz: 4.00 dBi
Power Consumption≤ 24 W
Power Method802.3at PoE+; 802.3af supported with reduced 5 GHz performance
MountingWall, Pole (Mounts Included)
Enclosure And Surge RatingIP Rating: IP68 Lightning Protection/Surge: ±4 kV
Operating And Storage ConditionsOperating Temperature: –30°C to +65°C (–22°F to +149°F) Storage Temperature: –40°C to +75°C (–40°F to +167°F) Operating Humidity: 5% RH to 95% RH (non-condensing) Storage Humidity: 5% RH to 95% RH (non-condensing)
Max. Number Of SSIDs8 per radio
Band SteeringYES
Wireless MeshingYES
802.1Q VLANYES
MLONO
4K-QAMNO
RF BeamformingYES
Client Device IsolationYES
Captive PortalYES
Lysora App ManagementYES
Local Web ManagementYES
Lysora Cloud ManagementYES
SNMPYES
Roaming802.11k/v/r; Layer 2 and Layer 3 roaming
BandsDual-band: 2.4 / 5 GHz (no 6 GHz radio)
