| Brand | Premium-NDAA |
|---|
| Model | HNC524N-VBA50-LPR |
|---|
| Image Sensor | 1/1.8-in. 4MP Progressive CMOS |
|---|
| Maximum Resolution | 2688 × 1520 (OSD Black Strip Excluded) |
|---|
| Minimum Illumination | 0.002 Lux (Built-In Illuminator On) |
|---|
| Number of Illuminators | Six (6) IR Illuminators With Adjustable Brightness |
|---|
| Illuminator Control | Automatic, Manual |
|---|
| Maximum Illumination Distance | Up to 30.0 m (98.4 ft) |
|---|
| Maximum Detection Speed | 80.5 km/h (50.0 mi/h) |
|---|
| Detection Width | 6.0 m to 7.0 m (19.7 ft to 23.0 ft) |
|---|
| Capture Distance | 8.0 m to 30.0 m (26.3 to 98.4 ft) |
|---|
| Trigger Mode | Video Detection, I/O Coil |
|---|
| Shutter Mode | Automatic, Manual 1/25 s–1/10,000 s |
|---|
| Lens Mount | Module |
|---|
| Iris Type | Automatic (W:1.33—T:1.34) |
|---|
| Lens Type | Motorized Vari-Focal |
|---|
| Focal Length | 10 to 50 mm (0.4 to 2.0 in.) |
|---|
| Field of View | Horizontal: 40.55° (W)–9.33° (T) Vertical: 22.7° (W)–5.3° (T) Diagonal: 46.6° (W)–10.63° (T) |
|---|
| Compression | H.265, H.264M, H.264H, MJPEG |
|---|
| Image Encoding Format | JPEG |
|---|
| Stream Capability | Two (2) Streams |
|---|
| Resolution | Main Stream: 4MP (2688×1520), 2MP (1600×1200), 1080p (1920×1080), 720p (1280 × 720) Sub Stream: 720p (1280 × 720), 960H (960× 480), D1 (704 × 480), CIF (352 × 240) |
|---|
| Maximum Frame Rate | Main Stream: 2688 x 1520/1600 x 1200/1920 x 1080/1280 x 720 at 30 fps Sub Stream: 1280 × 720/960 x 480/704 x 408/352 x 240 at 30 fps |
|---|
| Video Bit Rate | H.264/H.265: 4096 to 10240 kbps MJPEG: 8192 to 40960 kbps |
|---|
| Light Balancing | Wide Dynamic Range (96 dB) |
|---|
| White Balancing | Auto, Outdoor, Manual, Partial White Balance, Natural, Street Lamp |
|---|
| Exposure Mode | Manual, Auto |
|---|
| Noise Reduction | 3D NR, Video 3D NR, Video Spatial 3D NR, Video Temporal 3D NR |
|---|
| Edge Enhancement | Supported |
|---|
| OSD Overlay | Time, Plate, Vehicle (Color, Type) Vehicle Position, Counterfeit, Checkpoint Direction, Trigger Source, Custom |
|---|
| Image Tampering Prevention | Watermark, Verification Function |
|---|
| Vehicle Detection Rate | ≥ 99% |
|---|
| Vehicle Recognition Rate | ≥ 95% |
|---|
| Vehicle Recognition Attributes | Vehicle Color, Front-Seat Passenger, Licensed/Unlicensed |
|---|
| Interface | Output: One (1) Channel (RCA port) |
|---|
| Event | No SD Card, Insufficient Memory, SD Card Error, Offline, IP Conflict, Illegal Access, Security Exception |
|---|
| Interface | Input: 2-Channel Optocoupler (On/Off) Output: 2-Channel Relay (Can Be Used to Connect Other Devices) |
|---|
| Interface | One (1) RJ-45 (100/1000 Mbps Ethernet) Port, Two (2) RS-485 Ports, One (1) Wiegand Channel |
|---|
| Interoperability | ONVIF (Profile S/T), CGI, SDK |
|---|
| Auto Registration | Supported |
|---|
| Security | Username/Password, MAC Address Binding, HTTPS Encryption, IEEE 802.1×, Network Access Control |
|---|
| Automatic Network Replenishment (ANR) | Supported via Platform/FTP |
|---|
| Storage | Built-In 1 TF Card Port (Max. 128 GB) |
|---|
| Power Supply | 12 VDC, PoE+ |
|---|
| Power Consumption | < 20 W |
|---|
| Net Weight | 3.2 kg (7.05 lb) |
|---|
| Gross Weight | 5.2 kg (11.46 lb) |
|---|
| Operating Temperature | -30 to 65 °C (-22 to 149 °F) 10 to 90% RH (Non-Condensing) |
|---|
| Protection Ratings | IP67 |
|---|
| Product Dimensions (L × W × H) | 497.4 × 121.6 × 130.0 mm (19.6 × 4.8 × 5.1 in.) |
|---|
| Packaging Dimensions (L × W × H) | 625.0 × 305.0 × 270.0 mm (24.6 × 12.0 × 10.6 in.) |
|---|
| Electrical Box | Included |
|---|
| Certifications and Compliance | Metal and Plastic |
|---|
| Certifications | FCC, IC |
|---|
| Compliance | NDAA |
|---|
