| Brand | Premium-NDAA |
|---|
| Model | HNCA12N-FEU |
|---|
| Image Sensor | 1/1.7-in. 12MP Progressive CMOS |
|---|
| Maximum Resolution | 4000 x 3000 |
|---|
| Minimum Illumination | Color: 0.01 Lux (F2.0) Black/White: 0.001 Lux (F2.0) 0 Lux With IR Light On |
|---|
| Number of Illuminators | 3 IR LEDs |
|---|
| Illuminator Control | Automatic, Manual |
|---|
| Maximum Illumination Distance | IR Up to 10 m (30ft) |
|---|
| Electronic Shutter Speed | Automatic, Manual 1/3 s to 1/100,000 s |
|---|
| S/N Ratio | > 56 dB |
|---|
| Iris Type | Fixed |
|---|
| Lens Type | Fixed |
|---|
| Focal Length | 1.85mm |
|---|
| Maximum Aperture | F2.0 |
|---|
| Field of View | Horizontal: 185° Vertical: 180° |
|---|
| Close Focus Range | 0.4 m (1.31ft) |
|---|
| DORI Distance | Detect: 40.0 m (131.2 ft) Observe: 16.0 m (52.5 ft) Recognize: 8.0 m (26.2 ft) Identify: 4.0 m (13.1 ft) |
|---|
| Compression | Smart Encoding H.265+, H.265, Smart Encoding H.264+, H.264, MJPEG (Substream Only) |
|---|
| Standard Codec | Supported |
|---|
| Stream Capability | Three (3) |
|---|
| Resolution | 4000 × 3000 (12MP), 3280 × 2480 (8MP), 2880 × 2160 (6MP), 2048 x 1546 (3MP), 704 x 480 (D1), 352 x 240 (CIF) |
|---|
| Maximum Frame Rate | Mainstream: 4000 x 3000 at 25 fps Substream 1: 704 x 576 at 30 fps Substream 2: 1280 x 960 at 30 fps Fisheye Mode: 1O (4000 × 3000), 1P (4096 × 1024), 2P (2432 × 2432), 1R (1216 × 1216), 2R (2432 × 2432), 4R (2432 × 2432), 1O+3R (2432 × 2432) |
|---|
| Video Bit Rate | H.264: 3 kbps to 14,336 kbps H.265: 3 kbps to 16,384 kbps |
|---|
| Bit Rate Control | CBR/VBR |
|---|
| Day/Night | Auto (ICR), Color, Black and White |
|---|
| Noise Reduction | 3D NR |
|---|
| Light Balancing | DWDR |
|---|
| Image Angle | 0°/90°/180°/270° |
|---|
| Mirror Rotation | Supported |
|---|
| Region of Interest | Four (4) Zones |
|---|
| Privacy Masking | Four (4) Zones |
|---|
| Video Content Analytics+ | Line Crossing, Intrusion |
|---|
| Face Detection | Capture Snapshots and Facial Attributes |
|---|
| Heat Map | Supported |
|---|
| People Counting | Tripwire and In-Area People Counting, Queue Management With Report |
|---|
| Compression | PCM, G.711A, G.711Mu, G.726, G.723 |
|---|
| Interface | Input: Built-In Dual Microphone and 1-channel RCA Port Output: Built-In Speaker and 1-Channel RCA Port |
|---|
| Event | No SD Card, SD Card Full, SD Card Error, Network Disconnection, IP Conflict, Illegal Access, Motion Detection, Video Tampering, Voltage Detection, Security Exception, Tripwire, Intrusion, Scene Changing, Audio Detection, External Alarm, People Counting In Area, Stay Detection, People Counting, Security Exception |
|---|
| Interface | Input: Two (2) Channels 5mA 3V-5VDC Output: Two (2) Channels 1,000mA 30VDC/500mA 50VDC |
|---|
| Interface | RJ-45 (10/100 Base-T) |
|---|
| Protocol | IPv4, IPv6, TCP, UDP, RTP, RTCP, RTSP, RTMP, NTP, HTTP, ARP, SMTP, FTP, SFTP. DHCP, DNS, DDNS, QoS, UPnP, Multicast, ICMP, IGMP, NFS, PPPoE, SNMP, P2P |
|---|
| Interoperability | ONVIF (Profile S/G/T), API, SDK |
|---|
| Browser | Chrome, Firefox, Edge |
|---|
| Client | NeoViewer, NeoViewer App |
|---|
| Storage | FTP, SFTP, MicroSD Card (Max. 256 GB), NAS |
|---|
| Power Supply | 12 VDC, PoE+ (802.3at) |
|---|
| Power Consumption | < 13.9 W |
|---|
| Net Weight | 0.79 kg (1.74 lb) |
|---|
| Gross Weight | 1.21 kg (2.67 lb) |
|---|
| Operating Temperature | -40 °C to 60 °C (-22°F to 140°F) < 95% RH (Non-Condensing) |
|---|
| Storage Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
|---|
| Protection Ratings | IP67, IK10 |
|---|
| Product Dimensions (L x W x H) | 59.8 mm × Φ149.8 mm (2.35 in. × Φ5.90 in.) |
|---|
| Material | Metal |
|---|
| Certifications | FCC, IC |
|---|
| Compliance | NDAA |
|---|
| Electrical Box | HTH-285NJ-J03 |
|---|
| Wall Mount | HTH-272NJ-150B |
|---|
| Pole Mount | HTH-271NJ-150 |
|---|
| Pole Mount | HTH-271NJ-150-24 |
|---|
| Pole Mount | HTH-271NJ-150-36 |
|---|
