Lysora 12-Port 10G SFP+ Managed Switch

Description

Lysora LS3-12XS 12-Port 10G SFP+ Managed Switch

The Lysora LS3-12XS is a Layer 3 managed switch with twelve 10 Gigabit SFP+ ports and a stated 240 Gbps switching capacity. Static routing, OSPF and web, cloud or app management make it a compact option for aggregating high-speed network links.

Key Features

• 12 x 10G SFP+ ports
• 240 Gbps switching capacity and 178.56 Mpps forwarding rate
• IPv4 and IPv6 static routing; OSPFv2/v3
• 4094 VLANs and 32,000 MAC address entries
• VCS support for two members, as listed by Lysora
• Web, cloud and app management; SNMPv1/v2c/v3

Designed For Your Network

Bring multiple 10G connections together with twelve SFP+ interfaces. The all-SFP+ port layout suits a fiber-based aggregation layer where each access or distribution connection needs a high-speed uplink.

Build routed network segments using IPv4 and IPv6 static routes or OSPFv2/v3. VLAN support and access controls help organize traffic and apply network policy between connected systems.

Manage the switch locally or across distributed sites through the supported web, cloud and app interfaces. SNMPv1/v2c/v3, syslog and port mirroring support monitoring and troubleshooting.

Installation And Power

• Rack or desktop mounting; metal enclosure.
• Rated AC input: 100–240 V AC, 50/60 Hz.
• Two fixed fans use left-to-right airflow; operating temperature: 0–50°C.
• The official specification lists no RJ45 access ports or PoE output ports.

Management And Resources

Access supported devices through Lysora Cloud or the Lysora Cloud mobile app. Available functions depend on the model and firmware. Use the Downloads tab for verified app and document links.
