HNC328N-VDUZ

Premium-NDAA 8MP Dome Camera — 2.7~13.5mm

Resolution
8MP
Lens
2.7~13.5mm
Power Supply
12 VDC, PoE (802.3af)

$274.05

8MP Dome Camera — 2.7~13.5mm.

  • 8MP Turret Housing
  • 2.7 mm to 13.5 mm Motorized Lens
  • Dual-Illumination — IR and White-Light LEDs
Check CompatibilitySend your equipment model and setup details, and we’ll help check compatibility.

Accessories & compatibility

Product Information
SKU: HNC328N-VDUZ Category: Tags: , , , Brand:

Description

8MP Dome Camera — 2.7~13.5mm

The Premium-NDAA HNC328N-VDUZ is a 8mp dome camera for IP video surveillance. Review the lens, illumination and installation specifications to match it to your site.

Key Features

  • 8MP Turret Housing
  • 2.7 mm to 13.5 mm Motorized Lens
  • Dual-Illumination — IR and White-Light LEDs
  • Video Content Analytics: Line Crossing and Intrusion
  • IP67 Rating

Mounting Options

Suggested mounts: HTH-280NJ-J02, HTH-262NJ-W01, HTH-272NJ-120B, HTH-271NJ-120, HTH-275ZJ, HTH-276ZJ. Mounts are sold separately unless the package explicitly lists them as included. Pole and corner installations may require an additional wall bracket.

NeoViewer Mobile App

Connect your compatible Premium-NDAA camera or recorder with NeoViewer for mobile viewing and device management. Available functions depend on your model, firmware and system setup.

Additional information

Brand

Premium-NDAA

Model

HNC328N-VDUZ

Product Type

Dome Camera

Resolution

8MP

Lens

2.7~13.5mm

PLAN YOUR INSTALLATION

Accessories

Help me choose

Need help choosing an accessory for this product? Ask us to confirm compatibility before ordering.

Ask about compatible accessories

Downloads & Support

HNC328N-VDUZ

NeoViewer mobile viewing and device management. Available functions depend on the model, firmware and system setup. Contact EZDIYWORLD for help with setup, desktop software or product documents.

Need Help With This Product?

Technical Specifications

BrandPremium-NDAA
ModelHNC328N-VDUZ
Image Sensor1/2.7-in. 8MP Progressive CMOS
Maximum Resolution3840 x 2160
Minimum IlluminationColor: 0.007 Lux at F1.6 Black/White: 0.0007 Lux at F1.6 0 Lux With IR Light On
Number of IlluminatorsFour (4) White-Light LEDs, Four (4) IR LEDs, Supports
Illuminator ControlAutomatic, Manual, Zoom Priority
Maximum Illumination DistanceIR: Up to 61.0 m (200.0 ft) White Light: Up to 61.0 m (200.0 ft)
Electronic Shutter SpeedAutomatic, Manual 1/3 s to 1/100,000 s
Installation AnglePan/Rotation: 0° to 355° Tilt: 0° to 80°
S/N Ratio> 56 dB
Iris TypeFixed
Lens TypeMotorized Vari-Focal
Focal Length2.7 mm to 13.5 mm
Maximum ApertureF1.5
Field of ViewHorizontal: 114° to 32° Vertical: 58° to 17° Diagonal: 138° to 36°
Close Focus Range0.8 m (2.6 ft)
DORI DistanceDetect: 85.0 m to 279.5 m (278.9 ft to 917.0 ft) Observe: 33.9 m to 111.8 m (111.22 ft to 366.80 ft) Recognize: 16.9 m to 55.8 m (55.45 ft to 183.07 ft) Identify: 8.3 m to 27.8 m (27.23 ft to 91.21 ft)
CompressionSmart Encoding H.265+, H.265, Smart Encoding H.264+, H.264, MJPEG (Sub Stream Only)
Standard CodecSupported
Stream CapabilityTwo (2)
Resolution8MP (3840 x 2160), 6MP (3072 x 2048), 5MP (3072 x 1728), 5MP (2880 x 1620), 4MP (2688 x 1520), 3MP (2048 x 1536), 3MP (2304 x 1296), 1080P (1920 x 1080), 1.3MP (1280 x 960), 720P (1280 x 720), D1 (704 x 480), VGA (640 x 480), CIF (352 x 240)
Maximum Frame RateMain Stream: 8MP at 20 fps Sub Stream 1: D1 at 30 fps
Video Bit RateH.264: 3 kbps to 8,192 kbps H.265: 3 kbps to 8,192 kbps
Bit Rate ControlCBR/VBR
Day/NightAutomatic (ICR), Color, Black and White
Noise Reduction3D NR
Light BalancingWide Dynamic Range (120 dB)
Image Angle0°/90°/180°/270° (90°/270° Available for 2688 × 1520 Resolution or Lower)
Mirror RotationSupported
Region of InterestFour (4) Zones
Privacy MaskingFour (4) Zones
Video Content AnalyticsLine Crossing, Intrusion
Smart Motion DetectionSupported with Alarms for Vehicles and Humans
CompressionG.711a, G.711Mu, PCM
InterfaceInput: Built-in Microphone and One (1) RCA Input Output: One (1) RCA Output
EventLine Crossing, Intrusion, Motion Detection, Audio Detection, Video Tampering, Disk Full, Disk Error, Voltage Detection, Security Exception
InterfaceInput: One Port (Max. 5 VDC, 5 mA) One RCA Output: One (1) Port (Max. 12 VDC, 300 mA) One RCA
InterfaceRJ-45 (10/100 Base-T)
ProtocolPv4, IPv6, DNS, TCP, UDP, DHCP, HTTP, HTTPS, 802.1X, RTSP, DDNS, P2P, SMTP, RTMP, UPnP, Auto Registration, ICMP, IGMP, FTP, SFTP, RTP, RTCP, ARP, NTP, Multicast, NFS
InteroperabilityONVIF (Profile S/G/T), CGI
BrowserChrome, Firefox, Edge
StorageFTP, SFTP, Micro SD Card (Max. 256 GB)
Power Supply12 VDC, PoE (802.3af)
Power Consumption12 VDC • Maximum: 6 .9 W • Normal: 2.6 W PoE • Maximum: 8 .3 W • Normal: 3.3
Net Weight0.6 kg (1.3 lb)
Gross Weight0.7 kg (1.6 lb)
Operating Temperature-40 to 60 °C (-40 to 140 °F) < 95% RH (Non-Condensing)
Storage Temperature-40 to 60 °C (-40 to 140 °F)
Protection RatingsIP67, IK10
Product Dimensions (L x W x H)Φ 126.0 mm × 100.0 mm (Φ 5.0 in. × 4.0 in.)
Packaging Dimensions (L x W x H)148.0 mm x 139.0 mm x 137.0 mm (5.3 in. x 5.5 in. x 5.4 in.)
MaterialMetal (Housing), Plastic (Dome Covering)
CertificationsFCC, IC
ComplianceNDAA
Electrical BoxHTH-280NJ-J02 , HTH-280NJ-CJ11
Wall MountHTH-262NJ-W01 , HTH-272NJ-120B
PendantHTH-271NJ-120
2 to 4 ft. Telescope MountHTH-271NJ-120-24
3 to 6 ft. Telescope MountHTH-271NJ-120-36
